Understanding Insulation Materials and Options

Choosing insulation materials for busbars involves considering several tradeoffs based on their specific
properties and applications.

This new Applications Note details the tradeoffs for common insulation films used in busbars, including:

• PET (Polyethylene Terephthalate)
• Nomex
• Kapton
• PEN (Polyethylene Naphthalate)
• Epoxy Powder Coat

For each of the alternatives, the App Note lists key parameters and tradeoffs that should be taken into account when making a selection.

• Thermal Performance
• Electrical Insulation Properties
• Mechanical Strength and Flexibility
• Chemical Compatibility
• Cost and Availability

Click here to read the Applications Note on Understanding Insulation Materials Options for Busbars
